• When moving this machine self-propelled, take the “traveling posture” with which the boom
and hook block are stowed.
• Traveling or pick & carry with the boom extended is essentially prohibited. This will overturn
the machine, causing serious injury accidents.
• Follow the local laws and regulations if driving the machine on public roads.
Take the traveling posture shown on the right when moving the machine.
[1] TRAVELING BEFORE AND AFTER THE OPERATION, OR FOR TRANSPORTATION:
Keep the machine in the traveling posture as shown in the figure in
the right, when travel to and from an operation site or a
transportation depot.
• Retract the boom fully.
• Lower the boom fully.
• Stow the hook block to it‟s designated stowage position (regular
stowage position).
• Always direct the sprocket (A) backward.
[2] TRAVELING IN THE COURSE OF OPERATIONS:
Keep the machine in the traveling posture as shown in the figure
on the right, when traveling in the course of operations.
• Retract the boom fully.
• Lower the boom fully.
• Stow the hook block to it‟s temporary stowage position below the
boom tip.
• Always direct the sprocket (A) backward.
