3-137
[2] MOVING MACHINE BACKWARD]
1. Set lock lever (4) to the FREE position (F).
2. Operate blade control lever toward you to raise the blade.
3. Operate right and left travel levers (5) or right and left travel
pedals (6) as follows.
• When sprocket (A) is situated at the rear of the machine;
Start the machine either by pulling lever (5) back slowly or by
stepping on the rear part of pedal (6) slowly.
• When sprocket (A) is situated at the front of the machine;
Start the machine either by pushing lever (5) forward slowly or
by stepping on the front part of pedal (6) slowly.
• Check that the travel alarm sounds properly. If the travel alarm does not sound, please contact us or
our sales service agency.
• In cold temperature, if the machine travel speed is not normal, thoroughly perform the warming-up
operation. In addition, if the undercarriage is clogged with mud and the machine travel speed is not
normal, remove the soil and mud from the undercarriage.
• In a condition where the hook block is in the temporary stowage position, it may become loose due to
vibrations during traveling. In such an event, try a temporary stowage operation, again.
[3] STOPPING MACHINE
Avoid stopping suddenly. Give yourself ample room when
stopping.
• Put the left and right travel levers (5) to the NEUTRAL position,
and then stop the machine.
