4-19
9. With the wire rope (5) wound off of the winch drum (9), remove
the end of the wire rope (5) from the winch drum (9) by following
the procedure provided below.
(1) Bring a 6 to 10 mm round bar (A) into contact with the rope
wedge (10).
(2) Remove the rope wedge (10), lightly tapping the round bar
(A) with a hammer in the direction indicated by the arrow (b).
10. Wind up the remaining wire rope (5) completely.
Removal of the winch wire rope is completed.
