3-12
[2] HYDRAULIC OIL TEMPERATURE MONITOR
This monitor (2) warns operator that the hydraulic oil temperature
has risen.
If the hydraulic oil temperature becomes abnormally high, the
monitor shows abnormal display (C).
Stop operations and stop the engine or run it at low idling until
monitor (2) change to normal display (B).
• Display (A) at low temperatures: Monitor background (D) is white
• Display (B) at correct temperatures: Monitor background (D) is blue
• Display (C) when condition is abnormal: Monitor background (D) is red
[3] ENGINE OIL PRESSURE MONITOR
This monitor (3) warns operator that the engine lubrication oil
pressure has dropped.
If the engine lubrication oil pressure goes below normal level, the
monitor (3) lights up red.
Stop the engine immediately, check the lubrication system and
level of oil in the engine oil pan.
