3-14
[2] HYDRAULIC OIL TEMPERATURE MONITOR
If this monitor (2) shows low-temperature display (A), carry out the
warm-up operation.
For details, see “Operation 3.4.2 Hydraulic Equipment Warm
Up”.
This monitor (2) will show normal display (B), so carry out the
warm-up operation for hydraulic equipment.
• Display (A) at low temperatures: Monitor background (D) is white
• Display (B) at correct temperatures: Monitor background (D) is blue
• Display (C) when condition is abnormal: Monitor background (D) is red
[3] FUEL LEVEL MONITOR
This monitor (3) lights up to warn that the operator that the level in
the fuel tank is low.
When the remaining fuel level reaches approx. 33 liters, the
monitor lights up red, so add fuel as soon as possible.
[4] CHARGE LEVEL MONITOR
This monitor (4) warns the operator that there is an abnormality in
the charging system when the engine is running.
If the battery is not being charged properly while the engine is
running, monitor (4) lights up red.
If monitor (4) lights up red, check the V-belt for looseness. If any
abnormality is found, perform the necessary actions.
For details, see “Operation 9.5 Other Trouble”.
