Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual - 07/25/05
1-5
IMPULSE•VG+ Series 3 General Specifications
230V Class
460V Class
230V and 460V Classes
Specification Specification Values and Information for Each 230V-Class Model
2007 2009 2015 2023 2031 2045 2058 2071 2085 2145 2215 2283 2346
Rated current (A) 7 9.6 15 23 31 45 58 71 85 145 215 283 346
Capacity (kVA) 2.73.75.78.812172227325582110130
Specifi-
cation Specification Values and Information for Each 460V-Class Model
4002 4003 4005 4008 4012 4017 4024 4031 4039 4045 4060 4075 4091 4112 4150 4180 4260 4304 4370 4477 4590
Rated
current (A)
2.1 3.7 5.3 8.7 12.5 17 24 31 39 45 60 75 91 112 150 180 260 304 370 477 590
Capacity
(kVA)
1.6 2.8 4.0 6.6 9.5 13 18 24 30 34 46 57 69 85 110 140 200 230 280 390 510
Specification Specification Value and Information for All Models
Certification UL, CUL
Rated input power supply volts & freq 3-phase 200/208/220/230V or 380/400/415/440/460V/480V
Allowable input voltage fluctuation +10% or -15% of nominal
Allowable input frequency fluctuation ±5% of nominal
Control method Fully digital, flux vector control; sine-wave, pulse-width–modulated
Maximum output voltage (VAC) Max output voltage 3-phase, 200/208/220/230V; 380/400/415/440/460V/480V (proportional
to input voltage).
Rated frequency (Hz) Up to twice motor nameplate RPM (Ultra-Lift) 150 Hz standard (400 Hz, consult factory)
Output speed control range 1000:1
Output frequency accuracy .01%—with digital reference command
.1%—with analog reference command; 10 bits/10V
Frequency reference resolution Digital: .01 Hz; analog: .03 Hz (at 60 Hz)
Output frequency resolution .01 Hz
Overload capacity 150% of rated load for 1 min
Remote frequency reference sources 0–10VDC (20kΩ); 4–20mA (250Ω); ±10VDC serial (RS-485)
Accel/decel times 0.1 to 6000.0 sec—4 sets; 8 parameters are independently adjustable
Braking torque Approximately 20% if motor and inverter are sized 1:1; 150% or more with dynamic braking
(optional)
Motor overload protection UL recognized electronic thermal overload relay; field-programmable
Overcurrent protection level (OC1) 200% of rated current
Circuit protection Ground fault and blown-fuse protection
Overvoltage protection level 410/820VDC
Undervoltage protection level 190/380VDC
Heatsink overtemperature Thermostat trips at 105° C
Torque limit selection Separate functions for FORWARD, REVERSE, REGEN.; all selectable from 0–300%
