Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-73
Analog Inputs
The IMPULSE•VG+ Series 3 has three analog inputs (two multi-function and one reference) for the
external input of numerous references and limits.
* Initial value is determined by X-Press Programming (Table 4-1 to 4-2).
Parameter
Code Display Function Range
Initial
Value
Access
Level
H3-01* Term A1 LvL SeL Voltage for Terminal A1 analog
input signal
0-1 0 Adv
0 OVDC to 10VDC
1 -10VDC to +10VDC
H3-02 Terminal A1 Gain Gain multiplier for Terminal A1
analog input signal
0.0-1000.0% 100.0
H3-03 Terminal A1 Bias Bias multiplier for Terminal A1
analog input signal
-100.0–100.0% 0.0
H3-04 Term A3 Signal Voltage for Terminal A3 analog
input signal
0-1 0
0 0VDC to 10VDC
1 -10VDC to +10VDC
H3-05 Terminal A3 Sel Assigns one of the following
function analog input parameters to
Terminal A3
1F Adv
0 Add to Term A1 Auxiliary Reference
1 Frequency Gain Frequency Gain
2 Aux Speed Ref 1
3 Aux Speed Ref 2
5 Acc/Dec T Reduct Acceleration/Deceleration Time
Reduction
6 DC Brake Current
7 OT/UT Det Level Overtorque Detection Level
9 Ref Lower Limit Speed Reference Lower Limit
A Jump Frequency Jump Frequency
E Motor Temperature Used in conjunction with L1-03,
L1-04 and L1-05
10 Fwd Torque Limit
11 Rev Torque Limit
12 Regen Torque Limit
13 Torque Reference
14 Torque Compensation
15 FWD/REV Torque Limit
16 Load Cell Weight input enable by C10-01=4
17 Hook Height 10V=100.0%
1F Not Used Not Used
H3-06 Terminal A3 Gain Gain multiplier for Terminal 16
analog input signal
0000.0–
1000.0%
100.0 Adv
H3-07 Terminal A3 Bias Bias multiplier for Terminal 16
analog input signal
-100.0–100.0% 0.0 Adv
