IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-70
Digital Outputs—Alarm/Fault Annunciate (H2-01~03=40)
Digital Outputs—Fault Annunciate enables you to assign a set of six fault outputs to Relay Output
M3/M4 and/or Output M5/M6. In addition, you can select whether each fault output is enabled.
NOTE: Output M1/M2 can also be used for
Digital Outputs—Fault Annunciate; however, it is
normally assigned to a brake output.
Before you start to program this feature, you may find it convenient to first photocopy the “Binary-
to-Hexadecimal Conversion Worksheet” in this section. By being able to write in the worksheet’s
boxes, you will find it easier to program the feature.
Programming
Digital Outputs—Fault Annunciate requires that you determine two 4-digit binary
numbers and then convert these numbers to two 1-digit hexadecimal numbers. You enter the
hexadecimal numbers when you program the drive.
To program
Digital Outputs—Fault Annunciate (assuming you are in Programming Mode):
1. Press the UP button until appears.
2. Determine the output terminal to which you want Fault Annunciate assigned; Terminals M1-
M2, M3-M4 or M5-M6.
3. Press the button. “01” blinks. Press the UP arrow button to select Relay Outputs 2 or 3.
4. Press the DATA/ENTER button.
5. Press the UP or DOWN button until appears.
6. Press the DATA/ENTER button. appears.
7. From the following worksheet, select one of three fault output sets. (Each row is a set.)
Enter the one-zero combination that corresponds to the set (row) that you selected.
For example, if you selected Set 2, you would enter “1 0” in the first two columns from the left,
which would represent the first two digits of the first binary number that you would convert later.
Digital Outputs
H2-01=0
TERM M1-M2 SEL
>
H2-XX=40
Fault Annunciate
Fault Data Input
OF
Table 5-6:Binary-to-Hexadecimal Conversion Worksheet
First digit from the left Second digit from the left
Set 1 0 1 BE8 BE6 BE5 BE3 BE2 BE1
Set 2 1 0 OT1 OT2 LL1 LL2 UL1 UL2
Set 3 1 1 SLC BE4 BE3 BE2 BE1 BE0
1 or 0 1 or 0 1 or 0 1 or 0 1 or 0 1 or 0 1 or 0 1 or 0
To Next Page
