IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-88
Operator Parameters
• O1 Monitor Selection
• O2 Keypad Key Selection
•O3 Clear History
• 04 Copy Parameters
Monitor Selection
The top level in the operation mode allows the viewing of four monitor variables. They are Fref,
Fout, Iout, and User-Selected monitor. This user-selected monitor can be selected from the following
table. See Monitor Parameters table on page 5-109 for available monitors by control method
Parameter
Code Display Function Range
Initial
Value
Access
Level
O1-01 User Monitor Sel Assigns one of the following monitor
parameter as user-selected monitor.
4-53 6 Adv
4 Control Method
5 Motor Speed
6 Output Voltage
7 DC Bus Voltage
8 Output kWatts
9 Torque Reference
10 Input Term Sts
11 Output Term Sts
12 Int Ctl Sts 1
13 Elapsed Time
14 FLASH ID
15 Term A1 Level
16 Term A2 Level
17 Term A3 Level
18 Mot SEC Current
19 Mot EXC Current
20 SFS Output
21 ASR Input
22 ASR Output
23 PG-Z2 ch 2
24 PID Feedback
25 G5IN4 Reference
26 Voltage Ref (Vq)
27 Voltage Ref (Vd)
28 CPU ID
29 Load Weight
30 SS Delta Speed
32 ACR(q) Output
33 ACR(d) Output
34 OPE Detected
36 PID Input
