IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-90
Keypad Key Selection
Parameter
Code Display Function Range
Initial
Value
Access
Level
O2-01 Mode/Service Key
0 Mode/Service
Pressing the Mode/Service Key once
displays “Call ESI Service” 800-288-
8178.
Pressing the Mode/Service Key a
second time:
0Adv
1 Local/Remote Local/remote key is enabled
depressing the Mode/Service key
switches operation command between
the digital operator and the settings of
B3-01 and B3-02.
O2-02 Oper Stop Key Selects the action when the digital
stop key is pressed.
0Adv
0 Coast to Stop (Immediate stop)
1 Decel to Stop
2 Use B3-03 Method
O2-03 User Defaults 0 Adv
0 No Change
1 Set Defaults Memorizes up to 50 modified
parameters. User defaults can be
restored by setting
A1 - 05= “1110”.
2 Clear all Clear user defaults.
O2-04 Inverter Model # Determines the model number of the
drive, which is based on the kVA
rating. The following in this column
are Electromotive Systems model
numbers.
00-FF Adv
0 20P4 Not used.
1 20P7 Not used.
2 21P5 2007-FVG+S3
3 22P2 2009-FVG+S3
4 23P7 2015-FVG+S3
5 25P5 2023-FVG+S3
6 27P5 2031-FVG+S3
7 2011 2045-FVG+S3
8 2015 2058-FVG+S3
9 2018 2071-FVG+S3
A 2022 2085-FVG+S3
B 2030 Not Used.
XX
X
A
1-02
A
1-03
A
1-04
