Optional Digital Input Set-up (G5IN4 Digital Multi-Function Inputs)
The optional G5IN4 board accepts four additional multi-function inputs. The G5IN4 board has four
terminals, each of which can be programmed to one of the fourteen sets of inputs. Each input in the
set can be enabled or disabled.
1. Set C9-01 to 1.
2. Determine the parameter C9-02 setting
by specifying the first digit (from left)
and the fourth digit (from left) using
tables 5-3 and 5-4. The second and
third digit should always be “0”.
3. Set parameter C9-02.
Parameter
Code Display Function Range Initial Value
Access
Level
C9-01 G5IN4 0/1 Determines whether the
G5IN4 Digital Multi-Function
Inputs are enabled.
0Adv
0 Disabled
1 Enabled
C9-02 G5IN4 Setup Determines the four settings
for G5IN4 Digital Multi-
Function Inputs.
0000–FFFF 0 Adv
Table 5-2:
1 = 120V is present on terminal
0 = No voltage is present on terminal
MONITOR TERMINAL
U1-251234
11000
20100
31100
40010
51010
60110
71110
80001
91001
A0101
B1101
C0011
D1011
E0111
F1111
X00X
4th Dig
it
3rd Dig
it
2nd Dig
it
1st Dig
it
C
9-02 =
