Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-94
U1-39 Transmit Error n/a
U1-40 Fan Elapsed Time Hr
U1-41 Actual Fin Temp °C
U1-44 ARSR Out w/o Fil %
U1-49 Occupation Rate CPU Utilization %
U1-50 Hook Height %
U1-51 Motor Revolution # of Rev’s after UL2 n/a
U1-52 Maintenance Timer Hours since last timer reset Hr
U1-53 Index Count Numer of encoder pulses the shaft has moved since the beginning of
a new Index command in quadrature.
n/a
Fault Trace
U2-01 Current Fault Displays current fault
U2-02 Last Fault Displays last fault detected
U2-03 Frequency Reference Freq ref when fault was detected Hz
U2-04 Output Frequency Output freq when fault was detected Hz
U2-05 Output Current Output current when fault was detected A
U2-06 Motor Speed Motor Speed when the “Last Fault” occurred
U2-07 Output Voltage Output voltage when fault was detected V
U2-08 DC Bus Voltage DC Bus voltage when fault was detected V
U2-09 Output kWatts Output power when fault was detected kW
U2-10 Torque Reference Torque Reference when the “Last Fault” occurred
U2-11 Input Terminal Sts Input terminal status when fault was detected n/a
U2-12 Output Terminal Sts Output terminal status when fault was detected n/a
U2-13 Inverter Status Inverter status before fault was detected n/a
U2-14 Elapsed Time Elapsed time when fault was detected hours
Fault History
U3-01 Last Fault Most recent fault
U3-02 Fault Message 2 2nd most recent fault
U3-03 Fault Message 3 3rd most recent fault
U3-04 Fault Message 4 4th most recent fault
U3-05 Elapsed Time 1 Elapsed time of most recent fault
U3-06 Elapsed Time 2 Elapsed time of 2nd most recent fault
U3-07 Elapsed Time 3 Elapsed time of 3rd most recent fault
U3-08 Elapsed Time 4 Elapsed time of 4th most recent fault
U3-09 Fault Message 5 5th most recent fault
U3-10 Fault Message 6 6th most recent fault
U3-11 Fault Message 7 7th most recent fault
U3-12 Fault Message 8 8th most recent fault
U3-13 Fault Message 9 9th most recent fault
U3-14 Fault Message 10 10th most recent fault
Parameter
Code Display Function Units
001111 11
Not used
Parity error
Not used
Data Length error
CRC error
Over run error
Framing error
Time out
