IMPULSE•VG+ Series 3 Instruction Manual - 07/25/05
3-6
Suggested Circuit Protection Specifications and Wire Size
In order to comply with most safety standards, some circuit protective devices should be used
between the incoming three-phase power supply and the IMPULSE•VG+ Series 3. These devices
can be thermal, magnetic, or molded-case breakers (MCCB); or “slow-blow” type fuses such as
“CCMR” or “J.”
CAUTION:
The following guidelines are only suggested values. Always conform to local electrical
codes and wiring practices.
Wiring Size (AWG/KCMIL)
Model #
Rated
Current(A)
InputFuse
Time Delay
Input Fuse
Class
Inverse Time
Molded/Case
Circuit Breaker
Power Circuit
Wiring (1)
Control
Wiring
Ground
Copper (2)
230VClass
2007-FVG+-S3 12 CC 15 12 16/14 12
2009-FVG+-S3 15 CC 20 12 16/14 12
2015-FVG+-S3 25 CC 30 12 16/14 10
2023 -FVG+S3 30 J 45 12 16/14 10
2031 -FVG+S3 45 J 60 10 16/14 10
2045 -FVG+S3 60 J 90 6 16/14 10
2058 -FVG+S3 80 J 110 6 16/14 8
2071 -FVG+S3 100 J 150 4 16/14 8
2085 -FVG+S3 125 J 175 2 16/14 6
2145 -FVG+S3 200 J 300 1/0 16/14 6
2215 -FVG+S3 300 J 450 (2) 1/0 16/14 4
2283 -FVG+S3 400 J 600 (2) 1/0 16/14 2
2346 -FVG+S3 500 J 700 (2) 3/0 16/14 2
460VClass
4002 -FVG+S3 3.5 CC 15 12 16/14 12
4003 -FVG+S3 6 CC 15 12 16/14 12
4005 -FVG+S3 9 CC 15 12 16/14 12
4008 -FVG+S3 15 CC 20 12 16/14 12
4012 -FVG+S3 20 CC 25 12 16/14 12
4017 -FVG+S3 25 J 35 12 16/14 10
4024-FVG+S3 35 J 50 12 16/14 10
4031 -FVG+S3 45 J 60 10 16/14 10
4039 -FVG+S3 50 J 80 8 16/14 10
4045 -FVG+S3 60 J 90 6 16/14 10
4060-FVG+S3 80 J 125 4 16/14 8
4075 -FVG+S3 100 J 150 4 16/14 8
4091 -FVG+S3 125 J 175 2 16/14 6
4112 -FVG+S3 150 J 225 1/0 16/14 6
