Magnetek IMPULSE VG+ Series 3 - Accel;Decel Time Switching Frequency

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-13
Accel/Decel Time Switching Frequency
Accel/Decel times can be changed automatically without using multi-function inputs. When multi-
function contact inputs are set for Accel/Decel selection, this command has priority over automatic
change of Accel/Decel.
Parameter
Code Display Function Range
Initial
Value
Access
Level
B5-05 Accel Time N Chg Sets acceleration time at Speed Switch
frequency.
0.0–25.5 sec 2.0 Adv
B5-06 Dec Time N Chg Sets deceleration time at Speed
Switch frequency.
0.0–25.5 sec 2.0 Adv
B5-08 Fault Stop Time Sets deceleration time for complete
stop at external fault. See External
Response Selection page 5-89.
0.0–25.5 sec 0.5 Adv
B5-09 Acc/Dec Units Determines acceleration and
deceleration time interval and range.
1Adv
0 0.01sec for 0.00–2.55 sec Note: Setting will not change if any acc/dec time is > 255 sec.
1 0.1sec for 0.0–25.5
B5-10 Acc/Dec SW Freq Determines acceleration/deceleration
switching level
0.0–150.0Hz 60.0 Adv
B5-11 SW Freq Compare Determines when Acceleration Time
and Deceleration Time at Speed
Switch Hz is enabled;
1Adv
0 lower SW Freq 0: B5-05/06 is enabled, N-out≤B5-10
1 upper SW Freq 1: B5-05/06 is enabled, N-out≥B5-10
B5-12 Accel Time 3 Acceleration time when H1-01 to H1-
06 = 1B
0.0-6000.0 3.0 Adv
B5-13 Decel Time 3 Deceleration time when H1-01 to H1-
06 = 1B
0.0-6000.0 3.0 Adv
B5-14 Accel Time 4 Acceleraton time when H1-01 to H1-
06 = 1C
0.0-6000.0 3.0 Adv
B5-15 Decel Time 4 Deceleraton time when H1-01 to H1-
06 = 1C
0.0-6000.0 3.0 Adv
