IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-3
Application
• B1 Preset References
• B2 Reference Limits
• B3 Sequence/Reference Source
• B4 Trim Control Level
• B5 Acceleration/Deceleration
• B6 Phase Loss Detection
• B8 Jump Frequencies
Preset Reference
Parameter
Code Display Function Range
Initial
Value
Access
Level
B1-01* Reference 1 Sets the frequency of
Minimum Speed/Speed 1.
0.00–150.00 Hz** 15.00 Adv
B1-02* Reference 2 Sets the Speed 2 frequency. 0.00–150.00 Hz 30.00 Adv
B1-03* Reference 3 Sets the Speed 3 frequency. 0.00–150.00 Hz 60.00 Adv
B1-04* Reference 4 Sets the Speed 4 frequency. 0.00–150.00 Hz 45.00 Adv
B1-05* Reference 5 Sets the Speed 5 frequency. 0.00–150.00 Hz 60.00 Adv
B1-06* Reference 6 Sets the Speed 6 frequency. 0.00–150.00 Hz 0.00 Adv
B1-07* Reference 7 Sets the Speed 7 frequency. 0.00–150.00 Hz 0.00 Adv
B1-08* Reference 8 Sets the Speed 8 frequency. 0.00–150.00 Hz 0.00 Adv
B1-09* Reference 9 Sets the Speed 9 frequency. 0.00–150.00 Hz 0.00 Adv
B1-10* Reference 10 Sets the Speed 10 frequency. 0.00–150.00 Hz 0.00 Adv
B1-11* Reference 11 Sets the Speed 11 frequency. 0.00–150.00 Hz 0.00 Adv
B1-12* Reference 12 Sets the Speed 12 frequency. 0.00–150.00 Hz 0.00 Adv
B1-13* Reference 13 Sets the Speed 13 frequency. 0.00–150.00 Hz 0.00 Adv
B1-14* Reference 14 Sets the Speed 14 frequency. 0.00–150.00 Hz 0.00 Adv
B1-15* Reference 14 Sets the Speed 15 frequency. 0.00–150.00 Hz 0.00 Adv
B1-16* Reference 16 Sets the Speed 16 frequency. 0.00–150.00 Hz 0.00 Adv
B1-17* Jog Reference Jog Control and Inching
Control frequency reference.
0.00–150.00 Hz 6.00 Adv
B1-18* Ref Priority Determines whether the
digital or analog frequency
reference is used. NOTE:
When using Higher
Reference Select, 2-Step
Infinitely Variable should
NOT be used for a Speed
Reference setting in
parameter A1-04. The two
functions are not intended to
work in conjunction.
0Adv
0 Digital Ref Only
1 Analog Ref Only
2 Higher Ref Sel
* Initial value is determined by X-Press Programming (Table 4.1-4.2). **Maximum frequency above 150 HZ is
available, consult Electromotive Systems.
