Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
4-10
Select Motion (A1-03)
Set this parameter to match the motion of application. See tables 4.1 and 4.2 (X-Press Programming)
for details.
Speed Reference (A1-04)
This parameter will automatically define the input terminals for the selections listed below. See
tables 4.1 and 4.2 (X-Press Programming) for details.
Setting Description
0 Traverse - Decelerate to stop upon removal of RUN command.
2 No-Load Brake Hoist
Setting Description
0 2-SPD Multi-step — Defines Terminal 3 = 2nd speed.
1 3-SPD multi-step — Defines Terminals 3 and 4 as speeds 2 and 3 respectively.
2 5-SPD Multi-step — Defines Terminals 3-6 as speeds 2-5.
3 2-Step infinitely variable — Terminals 1 and 2 = b1-01 (Reference 1) and
speed hold. Terminal 3 = Accelerate.
4 3-Step infinitely variable — Terminals 1 and 2 = b1-01 (Reference 1).
Terminal 3 = Speed Hold. Terminal 4 =Accelerate.
5 Uni-polar analog — Terminals 1 and 2 = A directional input. Terminal 13 = 0-
10V. Terminal 14 = 4-20mA.
6 Bi-polar analog — Terminal 13 =-10 to +10V. An input on Terminal 1 is
required, but direction is determined by the reference given on Terminal 13.
7 Defines Terminals 3-8 as not used. Use this setting if using the G5IN4 option
card for inputting speed references.
8 Serial option card. Sets terminals to “not used.”
