IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-57
Option Parameters
•F1 Pulse Generator Option Set-up
•F2 Analog Input 14 Set-up
•F3 Digital Input Option Set-up
•F4 Analog Output Option Set-up
•F5 Digital Output 2 Set-up
•F6 Communication Card Set-up
Encoder (PG) Option Set-up
NOTE: *Fast-stop is selected, the stopping time is set by B5-08 (Fast stop time)
Parameter
Code Display Function Range
Initial
Value
Access
Level
F1-01 Pulses/Rev Sets encoder Pulses/Rev for
Channel 1
0–60000
pulses/rev
1024 Adv
F1-02 PG Fdbk Loss Sel Selects stopping method or alarm
output when PG line break is
detected (both channels).
0-3 1 Adv
0 Decel to Stop Decels to stop
1 Coast to Stop Immediate stop
2 Fast-Stop* Decel by B5-08
3Alarm Only Displayed on keypad only
F1-03 PG Overspeed Sel Selects stopping method or alarm
output when motor overspeed is
detected (both channels).
0-3 1 Adv
0 Decel to Stop Decels to stop
1 Coast to Stop Immediate stop
2 Fast-Stop* Decel by B5-08
3Alarm Only Displayed on keypad only
F1-04 PG Deviation Sel Selects stopping method when PG
deviation is detected.
0-7 5 Adv
at
speed
agree
0 Ramp to Stop Decels to stop by B5-02
1 Coast to Stop Immediate stop
2 Fast-Stop* Decel by B5-08
3Alarm Only Displayed on keypad only
at run
4 Ramp to Stop Decels to stop by B5-02
5 Coast to Stop Immediate stop
6 Fast-Stop* Decel by B5-08
7Alarm Only Displayed on keypad only
F1-05 PG Rotation Sel Selects PG rotation 0-1 0 Adv
0 Fwd = C.C.W.
1 Fwd = C.W.
F1-06 PG Output Ratio PG division rate (pulse output) 1-132 1 Adv
