IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-33
Table 5-3: G5IN4 Digital Multi-Function Input Sets (0 through F)
Multi-Function Input Assigned to Each Terminal
First Digit (From
Left) You Enter Terminal 1 Terminal 2 Terminal 3 Terminal 4
0 No function No function No function No function
1 Upper Limit–SLOW
DOWN; Normally Closed
Upper Limit–STOP;
Normally Closed
Lower Limit–SLOW
DOWN; Normally Closed
Lower Limit–STOP;
Normally Closed
2 Upper Limit–SLOW
DOWN; Normally Open
Upper Limit–STOP;
Normally Open
Lower Limit–SLOW
DOWN; Normally Open
Lower Limit–STOP;
Normally Open
3* Multi-Step Speed 2 Multi-Step Speed 3 Multi-Step Speed 4 Multi-Step Speed 5
4* Hold function (2nd step of
Three-Step Infinitely
Vari ab le) .
Acceleration function (2nd
step of Two-Step Infinitely
Variable or 3rd step of
Three-Step Infinitely
Variable).
Micro-Positioning Control
Multiplier 1
Upper Limit–STOP;
Normally Closed
5 Upper Limit–STOP
Normally Closed
Upper Limit–SLOW
DOWN; Normally Closed
Lower Limit–STOP;
Normally Closed
Lower Limit–SLOW
DOWN; Normally Closed
6 Upper Limit–STOP;
Normally Open
Upper Limit–SLOW
DOWN; Normally Open
Lower Limit–STOP;
Normally Open
Lower Limit–SLOW
DOWN; Normally Open
7* Multi-Step Speed 5 Multi-Step Speed 4 Multi-Step Speed 3 Multi-Step Speed 2
8* Upper Limit–STOP;
Normally Closed
Micro-Positioning Control
Multiplier 1
Acceleration function (2nd
step or Two-Step Infinitely
Variable or 3rd step of
Three-Step Infinitely
Vari ab le) .
Hold function (2nd step of
Three-Step Infinitely
Variable).
9 Upper Limit–STOP;
Normally Closed
Lower Limit–STOP;
Normally Closed
Micro-Positioning Control
Multiplier 1
External base block N/O
A Upper Limit–STOP;
Normally Closed
Lower Limit–STOP;
Normally Closed
Micro-Positioning Control
Multiplier 1
Weight Measurement
Control
B Ultra-Lift Enable Brake answerback Micro-Positioning Control
Multiplier 1
Micro-Positioning Control
Multiplier 2
C External Base Block N/O Phantom Fault N/O Klixon N/O BE6 Up Speed Limit
D External Base Block N/O Brake Answerback Micro-Positioning Control
Multiplier 1
Micro-Positioning Control
Multiplier 2
E Alternate Upper Limit
Frequency Reference
Option/Inverter Run and
Speed Reference
Changeover
Micro-Positioning Control
Multiplier 1
Brake Answerback
F External Base Block N/C Phantom Fault N/C Klixon N/C BE6 Up Speed Limit
* If using the G5IN4 to input speed references, A1-04 should be set for Data 7 (G5IN4 Opt Card). This will help to avoid and OPE03
fault caused by having more than one terminal programmed with the same data.
