Magnetek IMPULSE VG+ Series 3 - V;F Parameters

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-53
V/F Parameters
Parameter
Code Display Function Range
Initial
(1)
Value
Access
Level
E1-04 Max Frequency Maximum Frequency 40.0–150.0 Hz 60.0 Adv
E1-05
(2)
Max Voltage Maximum Voltage 0.0–510.0 V 460 Adv
E1-06 Base Frequency Motor Base Frequency 0.0–150.0 Hz 60 Adv
E1-09 Min Frequency Minimum Frequency 0.0–150.0 Hz 0.0 Adv
E1-11 Mid Frequency B Midpoint Output
Frequency B
0.0–150.0 Hz 0.0 Adv
E1-12 Mid Voltage B Midpoint Output
Voltage B
0.0–510.0 V 0.0 Adv
E1-13
(2)
Base Voltage Motor Base Voltage 0.0–510.0 V 0.0 Adv
* Initial value determined by X-Press Programming (Table 4.1 to 4.2).
(1)
The initial value displayed here is for 460V class drives.
(2)
For 230V class units, the value is half that of 400V class units.
