Monitor Parameters
Parameter
Code Display Function Units
Monitor
U1-01 Frequency Ref Frequency Reference Hz
U1-02 Output Frequency Inverter Output Frequency Hz
U1-03 Output Current Inverter Output Current A
U1-04 Control Method Displays the value of A1-02 n/a
U1-05 Motor Speed Motor Speed Hz
U1-06 Output Voltage Inverter Output Voltage (Reference) V
U1-07 DC Bus Voltage DC Bus Voltage (Measured) V
U1-08 Output kWatts Inverter Output Power (Calculated) kW
U1-09 Torque Reference Torque Reference (Internal) %
U1-10 Input Term Sts Input Terminal Status (See figure 5-35 for a detailed description.) n/a
U1-11 Output Term Sts Output Terminal Status (See figure 5-35 for a detailed description.) n/a
U1-12 Int Ctl Sts 1 Operation Status (See figure 5-35 for a detailed description.) n/a
U1-13 Elapsed Time Elapsed Time. See O2-07 and O2-08. hours
U1-14 Flash ID Flash ROM software ID number n/a
U1-15 Terminal A1 Level External Terminal input level V
U1-16 Terminal A2 Level External Terminal input level V/mA
U1-17 Terminal A3 Level External Terminal input level V
U1-18 Mot SEC Current Motor secondary current (lq). A
U1-19 Mot EXC Current Motor excitation current (ld). A
U1-20 SFS Output Primary freq. after the SFS Hz
U1-21 ASR Input Monitors the input to the speed regulator.
100%=FMAX
%
U1-22 ASR Output Monitors the output from the speed regulator.
The motor’s secondary current corresponds to 100%.
%
U1-23 PG-Z2 ch 2 Monitors the speed feedback from option card PG-Z2, channel 2
(when used)
HZ
U1-24 PID Feedback PID feedback signal level %
U1-25 G5IN4 Reference See page 5-32. Hex
U1-26 Voltage Reference (Vq) Motor secondary voltage reference V
U1-27 Voltage Reference (Vd) Motor excitation voltage reference V
U1-28 CPU ID CPU software ID number n/a
U1-29 Load Weight Monitors load weight when C10-01 is enabled tons
U1-30 SS Delta Speed Snap Shaft Delta Speed between Ch1 and Ch 2 after gear ratio HZ
U1-32 ACR (q) Output %
U1-33 ACR (d) Output %
U1-34 OPE Detected const #
U1-35 Zero Servo Pulse 4 times pulses of movement during zero servo n/a
U1-36 PID Input %
U1-37 PID Output %
U1-38 PID Set Point %
