Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-10
Input Scan Time
B3-06 selects the microprocessor scan time for reading sequence input data from the control circuit
terminals. Set B3-06 to “0” when a quicker response is needed from the control circuit terminal.
LOC/REM Run Select
If the run reference/speed reference are switched between serial mode and drive terminal mode, B3-
07 determines action after the switch.
Parameter
Code Display Function Range Initial Value
Access
Level
B3-06 Cntl Input Scans Selects the terminal scan time 0-1 1 Adv
0 2ms–2 scans
1 5ms–2 scans
Parameter
Code Display Function Range
Initial
Value
Access
Level
B3-07 LOC/REM Run Sel Determines action after switching Run/Speed
reference source.
0-1 0 Adv
0 Cycle Extrn Run If the run command is present at the time
when the Run/Speed reference source is
switched, it requires the run command to be
removed and then reapply the run command
from the new source to resume the normal
operation.
1 Accep Extrn Run If the run command is present at the time
when the Run/Speed reference source is
switched, it does not require the run command
from the new source to be removed. The
normal operation will continue.
B3-08 Run Command at Program 0-1 0 Adv
0 Disabled
1 Enabled (B3-02=0 is
Disabled)
B3-10 Allow Run at Power UP 0-1 0 Adv
0 Disabled
1 Enabled
B4-01 MOP Ref Memory Motor operated Pot frequency reference.
Enabled when mult. function input = 38, 3D,
or 3E. Will memorize previous held frequency
after a re-start or power is cycled.
0Adv
0 Disabled
1 Enabled
