IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-59
AI-14 Set-up
Sets CH1 to CH3 input functions when AI-14B option is connected (2CN).
When the 3CH individual input is used, parameter B3-01 is automatically set to “1” (frequency
reference from control circuit terminal). The option/inverter reference selection, which is selected by
a multi-function contact input (H1-XX= “1F”), is disabled when using the AI-14B option.
Sets CH1 to CH3 input functions when AI-14B option is connected
Digital Input Option Set-up
Selects the setting of the frequency reference input from the DI-08 and DI-16H option cards.
NOTE: B3-01 must be set to 3-option PCB when using these cards.
Parameter
Code Display Function Range
Initial
Value
Access
Level
F2-01 AI-14 Input Sel Determines whether the 3-
channel input selection is
individual or additional.
0Adv
0 3ch Individual
1 3ch Additional
Setting Function CH1 (TC1 to TC4 CH2 (TC2 to TC4) CH3 (TC3 to TC4)
0 3-channel individual input
(factory default)
Substitute for terminals
A1 & Ac
Substitute for terminals
A2 & AC
Substitute for
terminals A3 & AC
1 3-channel additonal input Sum of CH1 to CH3 input values is used as the frequency reference value
Paramete
r Code
Display
Function Range
Initial
Value
Access
Level
F3-01 DI Option Setup Selects the setting mode of the
reference input from the DI-08
and DI-16H options
0–7 0 Adv
0BCD 1% BCD 1% unit
1 BCD 0.1% BCD 0.1% unit
2 BCD 0.01% BCD 0.01% unit
3 BCD 1Hz BCD 1Hz unit
4 BCD 0.1Hz BCD 0.1Hz unit
5 BCD 0.01Hz BCD 0.01Hz unit
6 BCD (5DG) 0.01Hz Binary
DI–08: 255/100%
DI–16H, 12 bit selection: 4096/100%
DI–16H, 16 bit selection: 3000/100%
7 Binary Set value is displayed in decimal notation
