Parameter
Code Display Function Range
Initial
Value
Access
Level
F1-08 PG Overspd Level Motor overspeed detection level. 0–120% 105 Adv
F1-09 PG Overspd Time Motor overspeed detection time. 0–2.0 sec 0.0 Adv
F1-10 PG Deviate Level Excessive speed deviation level. 0–50% 10 Adv
F1-11 PG Deviate Time Excessive speed deviation time. 0–10.0 sec 0.3 Adv
F1-12 PG# Gear Teeth 1 PG Reduction Ratio 0-1000 0 Adv
F1-13 PG# Gear Teeth 2 PG Reducion Ratio
Ratio = 60 x F1-13
F1-12
Note: A Gear ratio of 1 will be
used if either perameter = 0
0-1000 0 Adv
F1-15 PGO Detect Time Open encoder circuit 0.00-10.00 0.50 Adv
F1-16 PG Ch 2 PPR Indicates how many pulses the
drive can expect per revolution of
the motor.
1-60000 PPR 1024 Adv
F1-17 PG Ch 2 Rotation O-FWD = CCW
1 - FWD = CW
0-1 0 Adv
F1-18 PGO-2-S Det Time Channel 2 open encoder circuit 0-10.0 Sec 0.5 Sec Adv
F1-19 PG-Z2 Output Set PG-Z2 Output 0-3 2 Adv
0 Select by MFI=41
1 Channel 1
2 Channel 2
3 Select by MFI=64
F1-20 PGO-1-H 0/1 CH1 Hardware PGO
enable/disable
0-1 1 Adv
0 Disabled
1 Enabled
F1-21 PGO-2-H 0/1 CH2 Hardware PGO
enable/disable
0-1 0 Adv
0 Disabled
1 Enabled
F1-22 PG-Z2 Input Sel Option Card PG-Z2 channel
select
0-1 0 Adv
0 Ch1 = motor 1, Ch 2 = motor 2
1 Ch 2 = motor 2, Ch 2 = motor 1
* Factory setting changes based on Control Method (A1-02)
