IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-20
Travel Limits
This function can automatically slow and stop a crane or hoist when it reaches the MS travel limits.
Two types of limit inputs (slowdown and stop) are available in both travel directions. Inputs can be
programmed through either GI F7 and G5IN4 cards.
Parameter
Code Display Function Range Initial Value
Access
Level
C3-01 Up Limit 1 Speed Speed at Upper Limit input. 0–400 Hz 6.00 Adv
C3-02 UL 1 Decel Time Decel time to Upper Limit
Speed.
0.0–25.5 sec 1.0 Adv
C3-03 UL 2 Stop Time Decel time to STOP when
Upper Limit is Input.
0.0–25.5 sec 1.0 Adv
C3-04 Low Limit 1 Speed Speed at Lower Limit input. 0–400 Hz 6.00 Adv
C3-05 LL 1 Decel Time Decel time to Lower Limit
Speed
0.0–25.5 sec 1.0 Adv
C3-06 LL 2 Stop Time Decel time to STOP when
Lower Limit is input.
0.0–25.5 sec 1.0 Adv
C3-07* Lmt Stop Method Determine the stop method at
Upper Limit 2 and Lower
Limit 2 Input.
0-2 2* Adv
0 Decel to Stop
1Coast to Stop
2 Use B3-03 Method
C3-08 UL3 Stop Method Weight Limit Stop Method
and action when Multi
Function Input = 12 or 62
0-5 4 Adv
0 Decel/Alarm (no further raise allowed)
1 Coast/Alarm (no further raise allowed)
2 Use B3-03 /Alarm (no further raise allowed)
3 Decel/Fault
4Coast/Fault
5 Use B3-03/Fault
Note: For setting 0, 2, 3, 5, deceleration is by B5-08.
C3-09 Phantom Stop Method Stopping Method when Multi
Function Input = 5F and 63
0-2 1 Adv
0 Decel to Stop
1Coast to Stop
2 Use B3-03 Method
* Initial value is determined by X-Press Programming
