IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-34
Table 5-4:Enabling/Disabling Decision Table for C9-02
Input for
Terminal 1
Input for
Terminal 2
Input for
Terminal 3
Input for
Terminal 4
Fourth Digit (From
Left) You Enter
E DDD 1
D E DD 2
EEDD 3
DDE D 4
E D E D 5
D EED 6
EEED 7
DDDE 8
E DDE 9
D E D E A
EED E B
DDEE C
E D EE D
D EEE E
EEEE F
Key Enable = E
Disable = D
