Page #131 background image
IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-78
Pulse Input/Output
Parameter
Code Display Function Range
Initial
Value
Access
Level
H6-01 Pulse Input Sel Selects the function of Pulse Input
Terminal RP
0–2 0 Adv
0 Frequency Reference
1 PID Feedback
2 PID Set Point
H6-02 Pulse In Scaling Number of pulses equal to the maximum
output frequency
1000-32000 1440 Hz Adv
H6-03 Pulse Input Gain Sets the output level when input is 100% 0.0-1000.0% 100.0 Adv
H6-04 Pulse Input Bias Sets the output level when input is ONE -100.0-
100.0%
0.0 Adv
H6-05 Pulse In Filter Sets the input filter time contant 0.00-2.00
sec
0.10 sec Adv
H6-06 Pulse Moni Sel Selects the function of pulse output
terminal MP.
1, 2, 5, 20,
24, 31, 36
2Adv
H6-07 Pulse Moni Scale Item output by pulse monitor is selected by
corresponding U1- Value.
0-32000 1440 Hz Adv
