Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-89
37 PID Output
38 PID Setpoint
39 Transmit Err
40 Fan Elapsed Time
41 Actual Fin Temp
44 ASR OUT w/o Fil
50 Hoook Height
51 Motor Revolution
52 Maintenance Timer
53 Index Count
O1-02 Power-On Monitor Selects the monitor to be displayed on
the digital operator immediately after
the power supply is turned on.
2Adv
1Frequency Ref (U1-01)
2 Output Freq (U1-02)
3 Output Current (U1-03)
4 User Monitor (01-01)
O1-03 Display Scaling Units for parameters and monitor
related to frequency reference and
output frequency can be scaled as
shown below.
0–39999 0 Adv
Table 5-14:
Setting (O1-03) Description
00000 Unit: 0.01Hz (factory default)
00001 Unit: 0.01%
00002 to 00039 Unit: rpm (set O1-03 equal to the number of motor poles)
00040 to 39999
(user-selected units)
Digits: 5th
4th 3rd 2nd 1st
0 0 0 0 0
The first through fourth digits determine the set value at 100% output frequency.
Decimal point position is set by the fifth digit as follows:
5th digit = 0: displayed as 0000
5th digit = 1: displayed as 000.0
5th digit = 2: displayed as 00.00
5th digit = 3: displayed as 0.000
Example 1
If 100% output frequency is equal to 200.0 units: Set O1-03=”12000”; 100% of this
reference is displayed as 200.0 and 60% of this reference is displayed as 120.0.
Example 2
If 100% output frequency is equal to 65.00: Set O1-03=”26500”; 60% of this reference is
displayed as 39.00.
Parameter
Code Display Function Range
Initial
Value
Access
Level
O1-04 Display Units Display units for motor speed 0 Adv
0) Hertz
1) RPM
O1-05 LCD Contrast Adjusts brightness of the keypad display 0-5 3 Adv
Parameter
Code Display Function Range
Initial
Value
Access
Level
