H3-08
Term A2 Signal Terminal A2 Signal Level Selection 0-2 2 Adv
0 0 to +10VDC
(Set S1-2 Dip Switch to
Off) *
1 -10 to +10VDC
(Set S1-2 Dip Switch to
Off) *
2 4 to 20mA (S1-2 Dip Switch must be ON)
H3-09 Terminal A2 Sel Assigns one of the following
function analog input parameters to
Terminal A2.
0Adv
0 Add to Term A1 Auxiliary Reference
1 Frequency Gain Frequency Gain
2 Aux Speed Ref 1
3 Aux Speed Ref 2
5 Acc/Dec T Reduct Acceleration/Deceleration Time
Reduction
7 OT/UT Det Level Overtorque Detection Level
9 Ref Lower Limit Speed Reference Lower Limit
A Jump Frequency Jump Frequency
E Motor Temperature Used in conjunction with L1-03,
L1-04 and L1-05
10 Fwd Torque Limit
11 Rev Torque Limit
12 Regen Torque Limit
13 Torque Reference
14 Torque Comp
15 FWD/REV Torque Limit
16 Load Cell Weight input enable by C10-01=4
17 Hook Height 10V=100.0%
1F Not Used Frequency Reference
H3-10 Terminal A2 Gain Gain multiplier for terminal A2
analog input signal
0000.0–
1000.0%
100.0 Adv
H3-11 Terminal A2 Bias Bias multiplier for terminal A2
analog input signal
-100.0–100.0% 0.0 Adv
H3-12 Filter Avg Time Analog input filter average time 0.00–2.00sec 0.00 Adv
* Damage may otherwise result. See page 3-11 for S1 Dip Switch Location
Parameter
Code Display Function Range
Initial
Value
Access
Level
