Magnetek IMPULSE VG+ Series 3 User Manual

IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-62
Selects the multi-function output selections for the DO-08 option.
Setting Terminal No. Description
0
8-Channel
individual
(factory fixed)
TD5/TD11 Overcurrent (SC, OC, GF)
TD6/TD11 Overvoltage (OV)
TD7/TD11 Inverter overload (OL2)
TD8/TD11 Fuse blown (FU)
TD9/TD11 Not used
TD10/TD11 Inverter overheat (OH)
TD1/TD2 During zero-speed detection
TD3/TD4 During speed agree
1
binary output
TD5/TD11
Binary output*
TD6/TD11
TD7/TD11
TD8/TD11
TD9/TD11 During zero-speed detection
TD10/TD11 During speed agree
TD1/TD2 During run
TD3/TD4 Minor fault
2
8-channel programmable
TD5/TD11 F5-01
TD6/TD11 F5-02
TD7/TD11 F5-03
TD8/TD11 F5-04
TD9/TD11 F5-05
TD10/TD11 F5-06
TD1/TD2 F5-07
TD3/TD4 F5-08
* When F5-09 is set to binary output (setting = “1”), use the table on the following page to read the DO-08 output.
TD8/TD11
(bit 3)
TD7/TD11
(bit 2)
TD6/TD11
(bit 1)
TD5/TD11
(bit 0) Description
0 0 0 0 No Fault
0 0 0 1 Overcurrent (SC, OC, GF)
0 0 1 0 Overvoltage (OV)
0 0 1 1 Inverter overload (OL2)
0 1 0 0 Inverter overheat (OH)
0 1 0 1 Overspeed (OS)
0 1 1 0 Fuse blown (FU)
0 1 1 1 Not used
1 0 0 0 External fault (EF3~EF8)
1 0 0 1 Controller fault
1 0 1 0 Motor overload (OL1)
1 0 1 1 Not used
1 1 0 0 Power loss (UV1, UV2, UV3)
1 1 0 1 Excessive speed deviation (DEV)
1 1 1 0 PG disconnection (PGO)
1 1 1 1 Not used
