IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-68
15 Freq Detect 3 Closed when output frequency
is ≤ L4-03
5-80
16 Freq Detect 4 Closed when output frequency
≥ L4-03
5-80
17 Trq Det 1 N.C. Open when torque > L6-02 5-82
18 Trq Det 2 N.O. Closed when torque > L6-05 5-83
19 Trq Det 2 N.C. Open when torque > L6-05 5-83
1A Forward Dir Closed when running FWD/
UP
n/a
1B Reverse Dir Closed when running REV/
DOWN
n/a
1C Switft/Ultra mode Swift/Ultra Lift is active n/a
1D BaseBlk N.C. During baseblock 2 n/a
1E Motor 2 Selected Closed when motor 2
changeover is input to
terminals
n/a
1F Regenerating Regenerating n/a
20 Auto-Rst Attempt Auto-Reset Enabled 5-85
21 Overload OL1 OL1 Overload fault code n/a
22 OH Prealarm Closed when “OH” is
displayed on keypad
n/a
23 Torque Limit Current Torque Limit n/a
24 Speed Limit Speed Limit n/a
25 Load Float Movement SC4-03 count n/a
26 Run Cmd is input During Run - ON: n/a
27 Load Check Det Load Check detected 5-24
28 Slack Cable Det Slack Cable Detection output 5-38
29 Upper Limit Closed when Upper Limit–
SLOW DOWN or Upper Limit
STOP is input
5-20
2A During Run 1 Used with Load Share 5-22
30 Lower Limit Closed when Lower Limit–
SLOW DOWN or Lower Limit
STOP is input
5-20
31 Up/Low Lmt Closed when Upper Limit–
SLOW DOWN or Upper Limit
STOP or Lower Limit– SLOW
DOWN or Lower Limit STOP
is input
5-20
32 Snap Shaft See C11-09 5-39
33 Weight Limit Enabled by C10-08
34 Index Complete Index move is complete
35 Torq Proving OK Torque Proving successful,
brake is released, drive ready
for F-Ref.
36 During Load FLT Drive in Load Float
37 Maintenance Timer reaches C12-05
38 Spd Lim @ Tcont On when in Torque Control
and output frequency is at
upper limit
39 Drive Enable Closed when drive enable is
active
Parameter
Code Display Function
Reference
Page
Number
