IMPULSE•VG+ Series 3 Instruction Manual - 07/25/05
2-9
460V Class
2283-FVG+S3 17.72
(450)
28.54
(725)
13.78
(350)
12.80
(325)
27.56
(700)
0.49
(12.5)
191 2800
2346-FVG+S3 19.69
(500)
33.46
(850)
14.17
(360)
14.57
(370)
32.28
(820)
0.59
(15)
238 3158
Overall Dimensions—in. &
(mm)
Mounting Dimensions—in. &
(mm)
Wt Lbs
Heat Loss
(W)
Model W H D W1 H1 H2 Total
4002-FVG+S3 5.51
(140)
11.02
(280)
6.30
(160)
4.95
(126)
10.47
(266)
0.28
(7)
6.6 58
4003-FVG+S3 5.51
(140)
11.02
(280)
6.30
(160)
4.95
(126)
10.47
(266)
0.28
(7)
6.6 84
4005-FVG+S3 5.51
(140)
11.02
(280)
7.09
(180)
4.95
(126)
10.47
(266)
0.28
(7)
8.8 115
4008-FVG+S3 5.51
(140)
11.02
(280)
7.09
(180)
4.95
(126)
10.47
(266)
0.28
(7)
8.8 148
4012-FVG+S3 5.51
(140)
11.02
(280)
7.09
(180)
4.95
(126)
10.47
(266)
0.28
(7)
8.8 208
4017-FVG+S3 7.87
(200)
11.81
(300)
7.87
(200)
7.32
(186)
11.22
(285)
.28
(7)
13.2 307
4024-FVG+S3 7.87
(200)
11.81
(300)
7.87
(200)
7.32
(186)
11.22
(285)
.28
(7)
13.2 390
4031-FVG+S3 9.45
(240)
13.78
(350)
8.27
(210)
8.5
(215)
13.19
(335)
0.30
(7.5)
22 465
4039-FVG+S3 9.45
(240)
13.78
(350)
8.27
(210)
8.5
(215)
13.19
(335)
0.30
(7.5)
22 590
4045-FVG+S3 10.98
(275)
17.72
(450)
10.24
(260)
8.66
(220)
17.13
(435)
0.30
(7.5)
53 653
4060-FVG+S3 10.98
(275)
17.72
(450)
10.24
(260)
8.66
(220)
17.13
(435)
0.30
(7.5)
53 988
4075-FVG+S3 12.80
(325)
21.65
(550)
11.22
(285)
10.24
(260)
21.06
(535)
0.30
(7.5)
88 1133
4091-FVG+S3 12.80
(325)
21.65
(550)
11.22
(285)
10.24
(260)
21.06
(535)
0.30
(7.5)
88 1287
4112-FVG+S3 12.80
(325)
21.65
(550)
11.22
(285)
10.24
(260)
21.06
(535)
0.30
(7.5)
88 1682
4150-FVG+S3 17.72
(450)
28.54
(725)
13.78
(350)
12.80
(325)
27.56
(700)
0.49
(12.5)
194 1847
4180-FVG+S3 17.72
(450)
28.54
(725)
13.78
(350)
12.80
(325)
27.56
(700)
0.49
(12.5)
196 2287
4260-FVG+S3 19.69
(500)
33.46
(850)
14.17
(360)
14.57
(370)
32.28
(820)
0.59
(15)
265 3393
4304-FVG+S3 22.64
(575)
36.06
(916)
14.88
(373)
17.52
(445)
33.66
(855)
0.59
(15)
352 3935
4370-FVG+S3 27.95
(710)
51.38
(1305)
16.26
(413)
10.63
(270)
50.00
(1270)
0.79
(20)
572 3964
4477-FVG+S3 27.95
(710)
51.38
(1305)
16.26
(413)
10.63
(270)
50.00
(1270)
0.79
(20)
616 5509
4590-FVG+S3 36.06
(916)
58.07
(1475)
16.26
(413)
14.37
(365)
56.70
(1440)
0.79
(20)
891 8320
Overall Dimensions
in inches and (mm)
Mounting Dimensions
in inches and (mm)
Wt Lbs
Heat Loss
(W)
Model W H D W1 H1 H2 Total
