Chapter 5: Operational Procedures
View Analogs
The View Analog Inputs screen can be viewed by the operator and will be displayed
on a screen similar to the following example.
Screen Type - Information
Analog Inputs Screen
The following table lists the various parameters displayed on the screen.
Analog Input Definitions
SCREW day mm/dd/yy hh:mm:ss
ANALOG INPUTS
CH NAME VALUE UNIT HEX CH NAME VALUE UNIT HEX
-- ------------------- ----- ---- ---- -- -------------------- ----- ---- ----
1 SUCTION PRESS XXX.X PSIG XXXX 9 MOTOR CURRENT XXX.X AMPS XXXX
2 DISCHARGE PRESS XXX.X PSIG XXXX 10 SLIDE VALVE POS SNSR XXX.X PCT XXXX
3 OIL PRESS AFTR FLTR XXX.X PSIG XXXX 11 PROCESS TEMP XXX.X DEGF XXXX
4 OIL PRESS BEFR FLTR XXX.X PSIG XXXX 12
5 DISCHARGE TEMP XXX.X DEGF XXXX 13
6 OIL TEMP XXX.X DEGF XXXX 14 VI SLIDE STOP SNSR X.XX XXXX
7 OIL SUMP TEMP XXX.X DEGF XXXX
8 SUCTION TEMP XXX.X DEGF XXXX
CP OIL PRESS XXX.X PSID
CP OIL FLTR DIFF PRESS XXX.X PSID
PARAMETER DEFINITION
CH
The analog channel number. CP represents a Computed Param-
eter derived from two or more analog channels.
NAME The name of the analog signal.
VALUE The decimal value of the analog input.
UNIT The units associated with the analog input.
HEX The hexidecimal value of the analog input.
