Chapter 3: Operational Procedures
Economizer Status Screen (Option)
The Economizer Status screen displays information pertaining to the Economizer
Control option. This screen is only present if the Economizer Control option is
enabled.
Economizer Status Screen
The following table lists the parameters displayed on the Economizer Status screen.
Economizer Status Definitions
M & M REFRIGERATION 8:32
AM
1. START ECONOMIZER STATUS
2.
STATS
3. MODE CONTROL MODE AUTO
4. SETPT
5. SCHED SOLENOID OPEN
6. CNTRL
7. MISC SLIDE VALVE POS XX
PCT
8. LOGS
9. MENUS
TERM DEFINITION
CONTROL MODE The current value of the Economizer mode.
SOLENOID The current state of the Economizer Solenoid output.
SLIDE VALVE POSITION The current value of the Compressor Slide Valve Position.
