Standard Screw Compressor - RWB Series
3-48
M&M
R
EFRIGERATION
I
NC
.
Active Group
The Active Group screen allows the user to select the current active group. This set-
ting will be active until a scheduling change or the operator modifies it. An example of
the screen is shown below.
Active Group Screen
The following table lists the data entry fields and a description of their purposes.
Active Group Definitions
M & M REFRIGERATION 8:32
AM
1. START
ACTIVE GROUP
2. STATS
3. MODE
GROUP NUMBER >G1
4. SETPT
5.
SCHED
6. CNTRL
7. MISC
8. LOGS
9. MENUS
TERM DEFINITION RANGE
GROUP
NUMBER
The active suction pressure control group for the system. If
Suction Pressure control is enabled, G1-G4 correspond to
Suction Pressure control groups S1-S4. If Process Tempera-
ture control is enabled, G1-G4 correspond to Process Tem-
perature control groups P1-P4.
G1-G4
