Standard Screw Compressor - RWB Series
5-28
M&M
R
EFRIGERATION
I
NC
.
Motor Configuration
The following table is a sample Motor Configuration screen.
Motor Configuration Screen
The following table list the data entry fields and a description of their purpose.
Motor Configuration Definitions
NOTE: Changing the CT Size may automatically adjust the Motor Current Setpoints.
M & M REFRIGERATION 8:32
AM
1. START MOTOR CONFIG
2. STATS
3. MODE CT SIZE XXX.X
AMPS
4. SETPT MOTOR VOLTS XXX
VOLT
5. SCHED POWER FACTOR XXX.X
PCT
6. CNTRL
7. MISC
8. LOGS
9. MENUS
TERM DEFINITION RANGE
CT
SIZE
Selects the size of the primary Current Transformer in the
motor starter. For example, a value of 500.0 amps represents
a CT with a 500:5 turns ratio.
0 - 2000 AMPS
MOTOR
VOLTS
Selects the voltage rating for the motor. 110 - 5000 VOLTS
POWER
FACTOR
Selects the power factor rating for the motor. 0-100 PCT
