Diagnostics

The Diagnostics menu option permits the user to view and in some cases alter basic infor-

mation about the system. The menu selections include viewing System Information, View-

ing IO, Analogs, and dip switches; and viewing Network Communications.

Diagnostics Screen

M & M REFRIGERATION 8:32

1. START DIAGNOSTICS

2. STATS 1.SYSTEM INFORMATION

3. MODE 2.VIEW DISCRETE I/O

4. SETPT 3.VIEW ANALOGS

5. SCHED 4.VIEW DIP SWITCHES

6. CNTRL 5.VIEW NETWORK COMM

7. MISC 6.OVERRIDE DISCRETE I/O

8. LOGS

9. MENUS
