Temperature Setpoints
The Temperature Setpoints menu allows the user to set temperature related set-
points described in the following sections.
Discharge Temperature Setpoints
The Discharge Temperature Setpoints screen allows the operator to set accept-
able ranges for the screw discharge temperature.
Discharge Temperature Setpoints Screen
The following table lists the data entry fields and a description of their purposes.
Discharge Temperature Definitions
M & M REFRIGERATION 8:32
AM
1. START
DISCHARGE TEMP SETPTS
2. STATS
3. MODE
HIGH FAILURE XXX.X
DEGF
4.
SETPT
HIGH ALARM XXX.X
DEGF
5. SCHED
6. CNTRL
7. MISC
8. LOGS
9. MENUS
TERM DEFINITION RANGE
HIGH FAILURE
The compressor is failed (stopped) when the discharge tem-
perature exceeds this value.
32 - 212
HIGH ALARM
The CCS reports an alarm to the operator when the dis-
charge temperature exceeds this value.
32 - 212
