Standard Screw Compressor - RWB Series
3-44
M&M
R
EFRIGERATION
I
NC
.
High Process Temperature Selection
The High Process Temperature Setpoints screen is only visible when the Process
Temperature Control option is enabled.
High Process Temperature SETPTS
The following table lists the parameter displayed on the process temperature set-
points screen.
High Process Temperature Definitions
M & M REFRIGERATION 8:32
AM
1. START PROCESS TEMP SETPTS
2. STATS
3. MODE HIGH FAILURE XXX.X
DEGF
4.
SETPT
HIGH ALARM XXX.X
DEGF
5. SCHED
6. CNTRL
7. MISC
8. LOGS
9. MENUS
TERM DEFINITION RANGE
HIGH
FAILURE
A failure is reported and the compressor is shutdown when
the Process Temperature rises above the High Failure set-
point.
-58 : 122 DEGF
HIGH
ALARM
An alarm is reported when the Process Temperature rises
above the High Alarm setpoint.
-58 : 122 DEGF
