Standard Screw Compressor - RWB Series
5-18
M&M
R
EFRIGERATION
I
NC
.
Dynamic Sensor Calibration
Dynamic Sensor Calibration is described more fully in the Technical Overview
section of this chapter.
Dynamic Sensor Calibration Screen
The following table lists the data entry fields and a description of their purpose.
Dynamic Sensor Calibration Definitions
SCREW COMPRESSOR day mm/dd/yy hh:mm:ss
DYNAMIC SENSOR CALIBRATION
CH NAME VALUE UNIT CH NAME VALUE UNIT
-- -------------------- ------- ---- -- ------------------- ------- ----
1 SUCTION PRESS XXXX.X PSIG 9 MOTOR CURRENT XXXX.X AMPS
2 DISCHARGE PRESS XXXX.X PSIG 10 SLIDE VALVE SNSR XXXX.X PCT
3 OIL PRESS AFTR FLTR XXXX.X PSIG 11 PROCESS TEMP XXXX.X DEGF
4 OIL PRESS BEFR FLTR XXXX.X PSIG 12
5 DISCHARGE TEMP XXXX.X DEGF 13
6 OIL TEMP XXXX.X DEGF 14 VI SLIDE STOP SNSR X.XX
7 OIL SUMP TEMP XXXX.X DEGF
8 SUCTION TEMP XXXX.X DEGF
SPAN CORRECTION XXX.X span/offset out of range
OFFSET CORRECTION XXX.X
TERM DEFINITION
CH The discrete channel number.
NAME The name of the discrete signal.
VALUE Current dynamic value of the discrete signal.
UNIT The unit of measurement for the discrete signal value.
