Standard Screw Compressor - RWB Series
C-26
M&M
R
EFRIGERATION
I
NC
.
Suction Pressure Setpoint Message Description
The Suction Pressure Setpoint message is a read/write message used to display or change
the four Suction Pressure control group setpoints. Suction Pressure setpoints may be read or
written individually or in groups. The master is responsible for setting the correct starting
address, number of registers, and the register data for the message block.
DF1
Word
Address
Modbus
Word
Address
Hex
Byte
Offset
Description Range Units
N12:0 40201 0000 S1 Suction Press Cut-In Setpoint 0 : 200 PSIA
1 40202 0002 S1 Suction Press Control Setpoint 0 : 200 PSIA
2 40203 0004 S1 Suction Press Cut-Out Setpoint 0 : 200 PSIA
3 40204 0006 S1 Suction Press Low Alarm 0 : 200 PSIA
4 40205 0008 S1 Suction Press Low Fail 0 : 200 PSIA
5 40206 000A S2 Suction Press Cut-In Setpoint 0 : 200 PSIA
6 40207 000C S2 Suction Press Control Setpoint 0 : 200 PSIA
7 40208 000E S2 Suction Press Cut-Out Setpoint 0 : 200 PSIA
8 40209 0010 S2 Suction Press Low Alarm 0 : 200 PSIA
9 40210 0012 S2 Suction Press Low Fail 0 : 200 PSIA
10 40211 0014 S3 Suction Press Cut-In Setpoint 0 : 200 PSIA
11 40212 0016 S3 Suction Press Control Setpoint 0 : 200 PSIA
12 40213 0018 S3 Suction Press Cut-Out Setpoint 0 : 200 PSIA
13 40214 001A S3 Suction Press Low Alarm 0 : 200 PSIA
14 40215 001C S3 Suction Press Low Fail 0 : 200 PSIA
15 40216 001E S4 Suction Press Cut-In Setpoint 0 : 200 PSIA
16 40217 0020 S4 Suction Press Control Setpoint 0 : 200 PSIA
17 40218 0022 S4 Suction Press Cut-Out Setpoint 0 : 200 PSIA
18 40219 0024 S4 Suction Press Low Alarm 0 : 200 PSIA
19 40220 0026 S4 Suction Press Low Fail 0 : 200 PSIA
