Standard Screw Compressor - RWB Series
3-42
M&M R
EFRIGERATION
I
NC
.
Oil Temperature Setpoints ( with Liquid Injection)
The liquid injection option adds two additional setpoint to the oil temperature set-
point screen. An example of the optional oil temperature setpoint screen is as fol-
lows.
Screen Type - Data Entry
The following table lists the data entry fields and a description of their purposes.
OIL TEMPERATURE
day mm/dd/yy hh:mm:ss
SETPOINTS
OIL TEMP HIGH FAILURE XXX.X DEGF
OIL TEMP HIGH ALARM XXX.X DEGF
LIQ INJECT CUT-IN XXX.X DEGF
LIQ INJECT CUT-OUT XXX.X DEGF
OIL SUMP HEATER CONTROL XXX.X DEGF
OIL SUMP LOW ALARM XXX.X DEGF
OIL SUMP LOW FAIL XXX.X DEGF
TERM DEFINITION RANGE
OIL TEMP HIGH FAILURE
The compressor will be failed (stopped) when the oil temper-
ature exceeds this value.
50-180
OIL TEMP HIGH ALARM
The CCS will report an alarm to the operator when the oil
temperature exceeds this value.
50 - 180
LIQ INJECT CUT-IN
The liquid injection solenoid will be opened when the oil tem-
perature rises above this value
50 -180
LIQ INJECT CUT-OUT
The liquid injection solenoid will be closed when the oil tem-
perature drops below this value
50 -180
OIL SUMP CONTROL The temperature at which to maintain the oil in the separator. 50 - 150
OIL SUMP
LOW ALARM
The CCS will report an alarm to the operator when the oil sum
temperature is below this value.
0 - 180
OIL SUMP
LOW FAILURE
The compressor will be failed (stopped) when the oil sump
temperature is below this value.
0 - 180
