Standard Screw Compressor - RWB Series
5-12
M&M
R
EFRIGERATION
I
NC
.
View Dip Switches
The screen shown below is an example of the View Dip Switches screen used for ver-
ifying the position of the dip switches on the microprocessor board.
NOTE: Dip switches should only be adjusted by qualified personnel.
Screw Dip Switch Screen
The following table lists the various parameters displayed on the screen.
Screw Dip Switch Definitions
SCREW day mm/dd/yy hh:mm:ss
DIP SWITCHES
SW SW1 STATE SW SW2 STATE SW SW3 STATE
-- ---------- ----- -- ---------- ----- -- ---------- -----
1 COMM ADDR OFF 1 OPTION OFF 1 OPTION OFF
2 COMM ADDR OFF 2 OPTION OFF 2 OPTION OFF
3 COMM ADDR OFF 3 OPTION OFF 3 OPTION OFF
4 COMM ADDR OFF 4 OPTION OFF 4 OPTION OFF
5 COMM ADDR OFF 5 OPTION OFF 5 OPTION OFF
6 COMM ADDR OFF 6 OPTION OFF 6 OPTION OFF
7 COMM ADDR OFF 7 OPTION OFF 7 OPTION OFF
8 COMM ADDR OFF 8 OPTION OFF 8 OPTION OFF
UNIT NUMBER xxx
PARAMETER DEFINITION
SW The dip switch number.
SW1
DIP Switch 1 on the main board. Used for communications unit
address
SW2 DIP Switch 2 on the main board. Used for options.
SW3 DIP Switch 3 on the main board. Used for options.
STATE Shows whether the dip switch is in the on or off state.
UNIT NUMBER Indicates the numeric value represented by SW1.
