HYDRAULIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
2-26
Published 05-03-17, Control # 228-03
P1537a
Item Description
1 Port A Multi-Function Valve
2 Port B Multi-Function Valve
3Protective Cap
4 Lock Nut
5 Adjusting Screw
6Bypass Hex
Wrench Size
Pump Size
Lock Nut
Hex Size
Internal
Hex Size
Series 130 Units
13 mm (1/2 in)
or
24 mm (15/16
in)
4 mm (5/32 in)
or
8 mm (5/16 in)
Multi-Function Valve
A1161
FIGURE 2-23
1
4
6
1
3 (5 under)
2
2
Typical Pump Installation
FIGURE 2-24
Typical Diagnostic Screen
(Screen for Drum 4 Shown)
Handle
Command
Drum
Speed
System
Pressure
Pump
Command
16-1013
