ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-26
Published 05-03-17, Control # 228-03
Digital Output Reference Chart
Table 3-4 Digital Outputs
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number)
CAN24-1-1 Cab Base RCL Beacon (N2) CAN26-2-32 Boom Hoist (Drum 5) Pawl – In (N6)
CAN24-1-2 Handle (H4) Rotation Indicator (N2) CAN26-2-64 Boom Hoist (Drum 5) Pawl – Out (N6)
CAN24-1-4 Handle (H2) Rotation Indicator (N2) CAN27-1-1 Counterweight Pins Disengage (N4)
CAN24-1-8 Front Wiper Switch (N2) CAN27-1-2 Drum 1 to Drum 2 Diversion Solenoid (N4)
CAN24-1-16 Overhead Wiper Switch (N2) CAN27-1-4 Drum 2 to Drum 1 Diversion Solenoid (N4)
CAN24-1-32 Handle (H3) Rotation Indicator (N2) CAN27-1-8 Drum 4 to Drum 5 Diversion Solenoid (N4)
CAN24-1-64 Handle (H1) Rotation Indicator (N2) CAN27-1-16 Left Travel to Drum 3 Diversion Sol. (N4)
CAN24-1-128 Handle Displays, Seat Switch (N2) CAN27-1-32 Right Travel to Drum 4 Diversion Sol. (N4)
CAN24-2-1 Travel 2-Speed, Travel Cruise Switch (N2) CAN27-1-64 Boom/Mast Hoist (Drum 4) Brake (N4)
CAN24-2-16 Limit Bypass and Jib Up Limit Switches (N2) CAN27-1-128 Boom/Mast Hoist (Drum 4) Motor Cont. (N4)
CAN24-2-128 Drum Park Switches (N2) CAN27-2-1 Pump 7 Control – Accessory Pump (N4)
CAN24-3-64 Foot Throttle Output (N2) CAN27-2-4 Left Front Jack Solenoid - Extend (N4)
CAN25-1-1 Cab Tilt Up Solenoid (N3) CAN27-2-8 Left Front Jack Solenoid - Retract (N4)
CAN25-1-2 Cab Tilt Down Solenoid (N3) CAN27-2-16 Right Front Jack Solenoid - Extend (N4)
CAN25-1-4 Rear Rotating Bed Pins - Extend (N3) CAN27-2-32 Right Front Jack Solenoid - Retract (N4)
CAN25-1-8 Rear Rotating Bed Pins - Retract (N3) CAN27-2-64 Left Rear Jack Solenoid - Extend (N4)
CAN25-1-16 Boom Hinge Pin – Extend (N3) CAN27-2-128 Left Rear Jack Solenoid - Retract (N4)
CAN25-1-32 Boom Hinge Pin – Retract (N3) CAN27-3-1 Right Rear Jack Solenoid - Extend (N4)
CAN25-1-64 Left Side RCL Capacity Alarm (N3) CAN27-3-2 Right Rear Jack Solenoid - Retract (N4)
CAN25-1-128 Load Hoist (Drum 2) LS Motor Control (N3) CAN27-3-4 Rigging Winch - Spool In (N4)
CAN25-2-1 Boom/Mast Hoist (Drum 4) Pawl – Out (N3) CAN27-3-8 Rigging Winch - Spool Out (N4)
CAN25-2-2 Boom/Mast Hoist (Drum 4) Pawl – In (N3) CAN27-3-16 Mast Raising Cylinders – Extend (N4)
CAN25-2-4 Left Side Swing/Travel Alarm Solenoid (N3) CAN27-3-32 Mast Raising Cylinders – Retract (N4)
CAN25-2-8 Accessory Proportional Relief Solenoid (N3) CAN27-3-64 Front Rotating Bed Pins - Retract (N4)
CAN25-2-16 Pump 4 Control – Drum 1/Drum 2 (N3) CAN27-3-128 Front Rotating Bed Pins - Extend (N4)
CAN25-2-32 Pump 4 Control – Drum 1/Drum 2 (N3) CAN29-1-1 Boom/Mast Hoist (Drum 4) Motor Cont. (N5)
CAN25-2-64 Pump 3 Control – Drum 4/Drum 5 (N3) CAN29-1-2 Engine Cooler Fan/Acc Enable Solenoid (N5)
CAN25-2-128 Pump 3 Control – Drum 4/Drum 5 (N3) CAN29-1-8 Right Side RCL Capacity Alarm (N5)
CAN25-3-1 Pump 6 Control – Drum 2/Drum 1 (N3) CAN29-1-64 Load Hoist (Drum 2) RS Motor Control (N5)
CAN25-3-2 Pump 6 Control – Drum 2/Drum 1 (N3) CAN29-1-128 Load Hoist (Drum 2) Brake Solenoid (N5)
CAN25-3-4 Pump 2 Control – Left Travel/Drum 3 (N3) CAN29-2-1 Right Side Swing/Travel Alarm (N5)
CAN25-3-8 Pump 2 Control – Left Travel/Drum 3 (N3) CAN29-2-2 Drum 2 Minimum Bail (N5)
CAN25-3-16 Pump 1 Control – Right Travel/Drum 4 (N3) CAN29-3-2 Travel Brake Release Solenoid (N5)
CAN25-3-32 Pump 1 Control – Right Travel/Drum 4 (N3) CAN29-3-4 Travel Two Speed Solenoid (N5)
CAN25-3-64 Pump 5 Control – Swing (N3) CAN29-3-8 Swing Brake Release Solenoid (N5)
CAN25-3-128 Pump 5 Control – Swing (N3) Not Used
CAN26-1-1 Load/Luffing (Drum 3) Brake Sol. (N6) Not Used
CAN26-1-2 Load/Luffing (Drum 3) RS Motor Cont. (N6) CAN29-3-64 Swing Bearing Grease Motor (N5)
CAN26-1-8 Load/Luffing (Drum 3) Pawl In (N6) CAN29-3-128 Crawler Track Grease Motor (N5)
CAN26-1-16 Load/Luffing (Drum 3) Pawl Out (N6) CAN129-1-1 System Operation Alarm (N1)
CAN26-1-32 Load/Luffing (Drum 3) Min. Bail Limit (N6) CAN129-1-4 RCL Warning L.E.D. (N1)
CAN26-1-64 Load Hoist (Drum 1) Brake Solenoid (N6) CAN129-1-32 RCL Caution L.E.D. (N1)
CAN26-1-128 Load Hoist (Drum 1) LS Motor Control (N6) CAN129-1-64 Displays 1 and 2 (N1)
CAN26-2-1 Load Hoist (Drum 1) RS Motor Control (N6) CAN129-2-2 Drum Handle Display H1 (N1)
CAN26-2-2 Load Hoist (Drum 1) Min. Bail Limit Sw. (N6) CAN129-2-8 Drum Handle Display H3 (N1)
CAN26-2-4 Boom Hoist (Drum 5) Brake Solenoid (N6) CAN129-2-16 Drum Handle Display H4 (N1)
CAN26-2-8 Boom Hoist (Drum 5) LS Motor Control (N6) CAN129-2-64 Drum Handle Display H2 (N1)
CAN26-2-16 Boom Hoist (Drum 5) RS Motor Control (N6)
