Reference Only
ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-22
Published 05-03-17, Control # 228-03
Boom Node 20 — Block-Up, Load Sensor, Angle Indicator, and Wind Speed
Reference Electrical Schematic A10871, Sheet 1, 11, and 20.
1
Packet number depends on specific attachment used.
Connector #
Function
Type
Description Test Voltage
CAN Packet
Number
J1 Receptacle – CAN In (From RCL Receiver) N/A
J201-A 24 Volts CAN Bus System 24 Volts Nominal N/A
J201-B BNSO Node Select Node Select Jumper to GND N/A
J201-C CANH CAN High Wire Transmission N/A N/A
J201-D Ground CAN Bus System Ground N/A
J201-E Ground Node Select Ground to AI-NS Ground N/A
J201-F CANL CAN Low Wire Transmission N/A N/A
J2 Receptacle – Upper Block Up N/A
J202-A 24 Volts Block Up Limit Boom Upper Point 24 Volts Nominal N/A
J202-B DI-2 Block Up Limit Boom Upper Point 0 Volts Off, 24 Volts On
CAN112-6-128
1
J3 Receptacle – Lower Block Up N/A
J203-A 24 Volts Block Up Limit Boom Lower Point 24 Volts Nominal N/A
J203-B DI-1 Block Up Limit Boom Lower Point 0 Volts Off, 24 Volts On
CAN112-6-64
1
J4 Receptacle – CAN Out N/A
J204-A 24 Volts CAN Bus System 24 Volts Nominal N/A
J204-C CANH CAN High Wire Transmission N/A N/A
J204-D Ground CAN Bus System Ground N/A
J204-E DI-ID To Jib Butt Cable Reel 0 Volts Off, 24 Volts On N/A
J204-F CANL CAN Low Wire Transmission N/A N/A
J8 Receptacle – Wind Speed N/A
J208-A AI-3 Wind Speed Sensor 0.05 to 16 Volts DC N/A
J208-B Ground Wind Speed Sensor Ground N/A
J9 Receptacle – Maximum Jib Angle Limit N/A
J209-A 24 Volts Maximum Jib Angle Limit 24 Volts Nominal N/A
J209-B DI-6 Maximum Jib Angle Limit 0 Volts Off, 24 Volts On CAN112-6-32
J11 Receptacle – Minimum Jib Angle Limit N/A
J2011-A 24 Volts Minimum Jib Angle Limit 24 Volts Nominal N/A
J2011-B DI-4 Minimum Jib Angle Limit 0 Volts Off, 24 Volts On CAN112-6-8
Boom Angle Indicator N/A
Wire 1 Ground Boom Angle Indicator Ground N/A
Wire 2 Signal Boom Angle Indicator Variable 0 to 5 Volts N/A
Wire 3 5 Volts Boom Angle Indicator 5 Volts Nominal N/A
