Manitowoc Published 05-03-17, Control # 228-03 3-27
16000 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
Digital Input Reference Chart
Table 3-5 Digital Inputs
MAX-ER CAN-28-2-64 Right Front Jacking Cylinder Extend (N7)
CAN-28-1-1 Counterweight Lift Cylinder Extend (N7) CAN-28-2-128 Right Front Jacking Cylinder Retract (N7)
CAN-28-1-2 Counterweight Lift Cylinder Retract (N7) CAN-28-3-1 Right Rear Jacking Cylinder Extend (N7)
CAN-28-1-64 Telescopic Beam Cylinder Extend (N7) CAN-28-3-2 Right Rear Jacking Cylinder Retract (N7)
CAN-28-1-128 Telescopic Beam Cylinder Retract (N7) CAN-28-3-4 Right Wheel Steering Clockwise (N7)
CAN-28-2-1 Telescopic Beam Hinge Pin In (N7) CAN-28-3-8 Left Wheel Steering Counter-Clock. (N7)
CAN-28-2-2 Telescopic Beam Hinge Pin Out (N7) CAN-28-3-16 Right Wheel Steering Clockwise (N7)
CAN-28-2-4 Left Front Jacking Cylinder Extend (N7) CAN-28-3-32 Right Wheel Steering Counter-Clock. (N7)
CAN-28-2-8 Left Front Jacking Cylinder Retract (N7) CAN-28-3-64 Left Wheel Brakes (N7)
CAN-28-2-16 Left Rear Jacking Cylinder Extend (N7) CAN-28-3-128 Right Wheel Brakes (N7)
CAN-28-2-32 Left Rear Jacking Cylinder Retract (N7)
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number
)
CAN43-1-1 Handle (H4) Direction Signal (N2) CAN129-3-4 Load Hoist (Drum 2) Park Switch (N1)
CAN43-1-2 Handle (H3) Direction Signal (N2) CAN129-3-16 Load Hoist (Drum 2) Park Switch (N1)
CAN43-1-4 Swing Holding Brake Switch (N2) CAN129-3-64 Travel Park Switch (N1)
CAN43-1-8 Swing Handle Direction Signal (N2) CAN129-3-128 Cab Tilt Up Switch (N1)
CAN43-1-32 Boom Raise Cylinder Retract CAN129-4-1 Display Enter Switch (N1)
CAN43-1-128 Boom Raise Cylinder Extend CAN129-4-2 Confirm Switch (N1)
CAN43-2-1 Left Track Direction Signal (N2) CAN129-4-4 Limit Bypass Switch (N1)
CAN43-2-2 Handle (H1) Direction Signal (N2) CAN129-4-8 Display Scroll Up Switch (N1)
CAN43-2-4 Handle (H2) Direction Signal (N2) CAN129-4-16 Jib Up Limit Bypass Switch (N1)
CAN43-2-8 Right Track Direction Signal (N2) CAN129-4-32 Display Scroll Down Switch (N1)
CAN45-1-4 Super Charge Pressure Switch (N3) CAN129-4-64 Travel Cruise Switch - On (N1)
CAN45-1-64 Hydraulic Charge Filter Alarm Switch (N3) CAN129-5-1 Seat Switch (N1)
CAN45-1-128 Hydraulic Return Filter Alarm Switch (N3) CAN129-5-2 Cab Tilt Up Switch (N1)
CAN47-1-8 Load/Luffing (Drum 3) Minimum Bail Limit (N6) CAN129-5-4 Regen Inhibit
CAN47-1-128 Load Hoist (Drum 1) Minimum Bail Limit (N6) CAN129-5-8 Air Conditioning Compressor Clutch On (N1)
CAN51-1-64 Left Front Jacking Cylinder Limit (N7) CAN129-5-16 Regen Initiate
CAN51-1-128 Left Rear Jacking Cylinder Limit (N7) CAN129-5-32 Engine Run/Start (N1)
CAN55-1-8 Maximum Boom Angle Limit Switch (N5) CAN129-5-128 Boom/Mast Hoist (Drum 4) Park Switch (N1)
CAN55-1-128 Drum 2 Minimum Bail Limit (N5) CAN129-6-4
Display 1 (N1)
CAN86-6-64 Block Up Limit Luffing/Fixed Jib Upper Pt. (N21) CAN129-6-8
Travel 2-Speed Switch (N1)
CAN86-6-128 Block Up Limit Luffing Jib Lower Point (N21) CAN129-6-16
Display 2 (N1)
CAN112-6-64 Block Up Limit Boom Upper Point (N20) CAN129-6-32 Swing Park Switch - On (N1)
CAN112-6-128 Block Up Limit Boom Lower Point (N20) CAN129-6-64
Display Exit Switch (N1)
CAN129-3-1 Boom Hoist (Drum 5) Park Switch (N1)
CAN129-6-128
Load/Luffing (Drum 3) Park Switch (N1)
