Manitowoc Published 05-03-17, Control # 228-03 1-11
16000 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
Undercarriage/Crawler
Item Description
1 Carbody Pedestal
2 Intermediate Crawler Roller (14 per crawler)
3 Crawler Roller (1 per crawler)
4 Right Crawler Pin Handle
5 Left Crawler Pin Handle
6 Crawler Input Planetary (both crawlers)
7 Crawler Brake (both crawlers)
8 Drive Shaft (both crawlers)
9 Crawler Output Gearbox (both crawlers)
10 Crawler Motor (both crawlers)
11 Carbody Jacks (European option)
P2285
1
P2299
P2230
P2243
P2298
FIGURE 1-6
P1426
3
5
4
6
7
8
9
10
2
1
11
P1430a
or
