ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-28
Published 05-03-17, Control # 228-03
MAX-ER Faults
Table 3-6 Digital Inputs
CAN Packet
Number
Item Description
(Node Number)
Wheeled MAX-ER
CAN147-1-1 Lift Cylinder Length Sensor Out of Range
CAN147-1-2 Lift Cylinder Retract Pressure Sensor Out of Range
CAN147-1-4 Lift Cylinder Extend Pressure Sensor Out of Range
CAN147-1-8 Top Reel Length Sensor Out of Range
CAN147-1-16 Bottom Reel Length Sensor Out of Range
CAN147-1-32 Bottom Reel Length Longer than Top Reel Length
CAN147-1-64 Top Reel Length Longer than Bottom Reel Length
CAN147-1-128 Fore-Aft Level Sensor Out of Range
CAN147-2-1 Port-Starboard Level Sensor Out of Range
CAN147-2-2 Out of Level
CAN147-2-4 Left Wheel Fault
CAN147-2-8 Right Wheel Fault
CAN147-2-16 Mast Strap Load Sensor Out of Range
CAN147-2-32 Mast Stop Sensor Out of Range
CAN147-2-64 Mast Stop Fault
CAN147-3-128 Set-Up Out of Level
CAN147-4-1 Set-Up Mast Stop Limit
CAN147-4-2 Set-Up Mast Stop Sensor Out of Range
Hanging MAX-ER
CAN147-2-128 Lift Cylinder Length Sensor Out of Range
CAN147-3-1 Lift Cylinder Retract Pressure Sensor Out of Range
CAN147-3-2 Lift Cylinder Extend Pressure Sensor Out of Range
CAN147-3-4 Mast Strap Load Sensor Out of Range
CAN147-3-8 Mast Stop Sensor Out of Range
CAN147-3-16 Mast Stop Fault
CAN147-3-32 Set-Up Mast Stop Limit
CAN147-3-64 Set-Up Mast Stop Sensor Out of Range
