ELECTRIC SYSTEM 16000 SERVICE/MAINTENANCE MANUAL
3-12
Published 05-03-17, Control # 228-03
Node 4 — Pressure Senders, Drum 4, and Accessories
Reference Electrical Schematic A10871, Sheet 1, 8, and 16.
Connector #
Function
Type
Description Test Voltage
CAN Packet
Number
Input/output cable routing to remote nodes vary - see Electrical Schematic specific to your crane.
W43 Receptacle - Pressure Senders
W43-A Ground Counterweight Pins Disengage Solenoid Ground N/A
W43-B DO-1 Counterweight Pins Disengage Solenoid 0 Volts Off, 24 Volts On CAN27-1-1
W43-C Ground Drum 1 to Drum 2 Diversion Solenoid Ground N/A
W43-D DO-2 Drum 1 to Drum 2 Diversion Solenoid 0 Volts Off, 24 Volts On CAN27-1-2
W43-E Ground Drum 2 to Drum 1 Diversion Solenoid Ground N/A
W43-F DO-3 Drum 2 to Drum 1 Diversion Solenoid 0 Volts Off, 24 Volts On CAN27-1-4
W43-G Ground Drum 4 to Drum 5 Diversion Solenoid Ground N/A
W43-H DO-4 Drum 4 to Drum 5 Diversion Solenoid 0 Volts Off, 24 Volts On CAN27-1-8
W43-J Ground Left Travel to Drum 3 Diversion Solenoid Ground N/A
W43-M NS-3 Node Select Jumper to Ground Solenoid 0 Volts (with Jumper) N/A
W43-N Ground Right Travel to Drum 4 Diversion Solenoid Ground N/A
W43-P DO-6 Right Travel to Drum 4 Diversion Solenoid 0 Volts Off, 24 Volts On CAN27-1-32
W43-R DO-5 Left Travel to Drum 3 Diversion Solenoid 0 Volts Off, 24 Volts On CAN27-1-16
W43-U 24 Volts Load Hoist (Drum 1) Pressure Sender 24 Volts Nominal N/A
W43-V 24 Volts Load Hoist (Drum 2) Pressure Sender 24 Volts Nominal N/A
W43-b AI-2 Load Hoist (Drum 1) Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN12-4
1
W43-d AI-4 Load Hoist (Drum 2) Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN12-8
1
W43-g Ground Load Hoist (Drum 1) Pressure Sender Ground N/A
W43-h Ground
Right Travel Reverse Pressure Sender/
Jumper to Node Select 3
Ground N/A
W43-k Ground Load Hoist (Drum 2) Pressure Sender Ground N/A
W43-m Ground Drum 4 or Drum 5 Pressure Sender Ground N/A
W43-n 24 Volts Right Travel Reverse Pressure Sender 24 Volts Nominal N/A
W43-p AI-7 Right Travel Reverse Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN13-6
1
W43-r AI-8 Drum 4 or Drum 5 Pressure Sender 1 V at 0 psi, 5 V at 7,000 psi
CAN13-8
1
W43-s 24 Volts Drum 4 or Drum 5 Pressure Sender 24 Volts Nominal N/A
W44 Receptacle – Accessories
W44-A Ground Left Front Jack Solenoid - Extend Ground N/A
W44-B DO-11 Left Front Jack Solenoid - Extend 0 Volts Off, 24 Volts On CAN27-2-4
W44-C Ground Left Front Jack Solenoid - Retract Ground N/A
W44-D DO-12 Left Front Jack Solenoid - Retract 0 Volts Off, 24 Volts On CAN27-2-8
W44-E Ground Right Front Jack Solenoid - Extend Ground N/A
W44-F DO-13 Right Front Jack Solenoid - Extend 0 Volts Off, 24 Volts On CAN27-2-16
W44-G Ground Right Front Jack Solenoid - Retract Ground N/A
W44-H DO-14 Right Front Jack Solenoid - Retract 0 Volts Off, 24 Volts On CAN27-2-32
W44-J Ground Left Rear Jack Solenoid - Extend Ground N/A
W44-K Ground Right Rear Jack Solenoid - Retract Ground N/A
W44-L Ground Right Rear Jack Solenoid - Extend Ground N/A
W44-M DO-17 Right Rear Jack Solenoid - Extend 0 Volts Off, 24 Volts On CAN27-3-1
W44-N Ground Left Rear Jack Solenoid - Retract Ground N/A
To Next Page
