Manitowoc 16000 - Assorted Views

Reference Only
INTRODUCTION 16000 SERVICE/MAINTENANCE MANUAL
1-6
Published 05-03-17, Control # 228-03
Assorted Views
Item Description Item Description
1 Boom/Mast Drum 10 Crawler Auto Lube Pump
2 Sequence Valve (all drum motors) 11 Left and Right Swing Gearboxes
3 Boom/Mast Motor 12 Turntable Auto Lube Pump
4 Load Drum Motor 13 Swing Gears
5 Load Drum 14 Turntable Bearing
6 Drum Speed Sensor (all drums) 15 Hydraulic Tank Shut-off
7 Node-6 Controller 16 Drum 4 Pawl
8 Electrical Cable Reel 17 Drum 4
9 Rigging Winch
P2241
P2238
FIGURE 1-2
P2304
P2270a
P2297
P2303
P2312
1
2
4
3
6
8
9
15
11
12
13
14
10
7
5
16
In Boom Butt
P2342a
17
